Hydraulic Pump Housing — 7075-T6 Aluminum, 5-Axis CNC Milled, Hard Anodized
LouTech machines hydraulic pump housings from 7075-T6 aluminum (UTS 83 ksi) on 5-axis HAAS UMC-750 machining centers to customer-released engineering drawings, holding port bore concentricity to ±0.0005" and surface finish of 32 µin Ra on sealing surfaces, with Type III hard anodize (0.002" per side, Rockwell 60–70 HRC surface hardness) for wear resistance on internal sliding surfaces — serving commercial and military aircraft hydraulic actuation system OEMs with AS9100 lot documentation.
Build Specifications
| Property | Value |
|---|---|
| Material | Aluminum |
| Alloy/Temper | 7075-T6 |
| UTS | 83 ksi |
| Finish | Type III Hard Anodize — 0.002" per side, 60–70 HRC surface hardness |
| Bore Tolerance | ±0.0005" port bore concentricity |
| Surface Finish | 32 µin Ra on sealing surfaces |
| Port Count | Per customer engineering drawing |
| Manufacturing Process | 5-Axis CNC Milling — HAAS UMC-750 |
| CAGE Code | LouTech LLC — Chino, CA |
